Drive units

1 x 25mm dome high frequency drive unit

1 x 165mm low frequency drive unit

Frequency response

70Hz to 20kHz +/- 3dB

HF control

+3dB / 0dB / -3dB

Power Handling

40W

Impedance

12 Ohm

Dispersion

120 degrees Horizontal -6dB at 6kHz

Finish

White grille

Fixing

4 swing-out clamps

Dimensions (mm)

231.9mm diameter x 83.8mm deep

Weight

1.63Kg

The Median IC 165 from Audica Professional is a premium ceiling loudspeaker designed for applications where high fidelity audio quality is a primary requirement. The open back design saves depth and weight for installations where a sealed enclosure (back-can) is not required.

The IC 165  features a swivel HF unit, to direct the sound to the required listening area, and incorporate an HF cut/boost control to shape the frequency response for the application or room acoustics.

The loudspeaker is quick to install with swing out legs for secure fitting and the ultra-low profile grille is magnetically mounted for a fast fit and a clean, discreet appearance.

Requiring no signal processing, the Median IC 165 loudspeakers is ideally suited for use in systems with the Audica Professional MULTIzone controller (EQ setting flat) and the MICROplus power amplifier.





Downloads:

MEDIANseries spec sheet (pdf)

MEDIANseries manual (pdf)

MEDIANseries photographs (jpeg/zip)
