Drive units

20mm dome HF with 4-inch bass unit and a
4-inch passive radiator

Frequency response

80Hz - 30kHz (no EQ required)

Power Handling

100 Volt and 8 Ohm switching

Switchable 2, 4, 8 and 16W 100V / 30W 8 Ohm

Finish

White

Mounting

Ceiling or wall mount

Dimensions (mm)

146 x 376 x 127mm

Weight

3.00 kg

Downloads:

MEDIAtrac manual

MEDIANseries brochure (pdf)

MEDIANseries photographs (jpeg/zip)



Home.
News / Installations.
Product Range.
Downloads / Warranty.
Distributors.
Contact.

MEDIAtrac is a high quality loudspeaker for music, audio visual and speech applications, including retail outlets, bars and restaurants, hotels, education establishments, meeting rooms, museums and visitor centres.

The extruded aluminium body houses a 20mm dome high frequency unit, 4-inch bass unit and 4-inch passive bass radiator. The unit is designed for 8 Ohm low impedance and 100V line use, and is adjustable via a tap switch located discretely behind the removable front grille.

Finished in white, MEDIAtrac is supplied complete with an adjustable yoke bracket for fast and reliable installation.
