Community and Audica Professional Provide Modern Audio for Historic Cracow University
Tommex Żebrowscy Sp. J. has recently designed, supplied and installed new audio systems
for the Kotłownia, the conference and exhibition hall of The Tadeusz Kościuszko Cracow
University of Technology (Politechnika Krakowska).
Incorporating a large conference room and an art gallery with two exhibition rooms,
the Kotłownia, translation “boiler house”, takes its name from its former use after
World War II. The current appearance of this historical building is the result of
a modernization program which was carried out in the period from 1997 to 2001.
For the conference room, which seats 220, high intelligibility and precise pattern
control to cover the delegate area were the essential parameters. To meet these requirements
Tommex installed two Community’s ENTASYS™ three-way, full-range, column-line-array
loudspeaker systems. These are supplemented by a low-profile Community VLF208 subwoofer
for extended low frequency performance. The system is driven by a Dynacord DSA 8410
amplifier, equipped with an RCM810 IRIS-Net module for remote control and supervision,
and processing is provided by a Dynacord DSP 600.
The gallery required a high quality, wide coverage background music and speech system
and Tommex chose Audica Professional’s MICROseries. The system consists of a MICROzone
preamp/controller, a MICROplus 4-channel power amplifier, and eight MICROline loudspeakers.
An Audica IR receiver was also installed in the gallery to allow the MICROzone to
be remote-controlled from within the room.
A Dynacord CMS compact mixer feeds both systems, allowing for a common signal to
both or for each system to be used independently.
